產品特點:
|
照明 |
|
|
功率x燈數 |
1000W×1 |
|
光通量（Lm） |
110000 |
|
燈泡 |
氣體放電燈（金鹵燈） |
|
照明半徑 |
500-650 |
|
照明范圍（㎡） |
3000 |
|
燈桿 |
|
|
燈架操作 |
三節升降桿 |
|
升高高度mm |
4200 |
|
收納高度mm |
1800 |
|
升降方式 |
氣動升降 |
|
抗傾斜度 |
＜10° |
|
抗風力 |
＜6級 |
|
發動機 |
|
|
型號 |
HONDA ER2500 |
|
類型 |
空冷，4沖程，OHV，汽油發動機 |
|
油箱容積 |
15L |
|
連續工作時間 |
13h |
|
發電機類型 |
單向交流發電機 |
|
頻率 |
50Hz |
|
最大功率 |
2.2KVA |
|
額定功率 |
2.0KVA |
|
絕緣等級 |
B |
|
包裝尺寸 |
|
|
主機 |
1100x850x800mm |
|
升降桿 |
1800x200x150mm |
|
燈頭 |
700x350x350mm |
|
重量 |
110kg |
| Genshent Technical Data | MO-1200Q | MO-1100Q | MO-400Q |
| 20" / 40" Loading Pcs | 20 / 40 PCS | 36 / 72 PCS | 80 / 160 PCS |
| Mast Height (Fully Extenled) | 5m | 4m | 2.8m |
| Weight ( Net ) | 210kg | 98kg | 64kg |
| Rated Voltage | 220V(Single Phase ) | 220V(Single Phase ) | 220V(Single Phase ) |
| Rated Power | 3.6KVA | 2.2KVA | 0.7KVA |
| Power Outlet Sockets | 2PCS*10A | 2PCS*10A | 2PCS*10A |
| Input Voltage | 220V(Single Phase) | 220V(Single Phase) | 220V(Single Phase) |
| Fuel Tank Capacity | 25Liters | 15Liters | 4.2Liters |
| Fuel Tank Operating Hours | 15 hours | 13 hours | 6.3 hours |
| Fuel Consumption (g/kw.h) | NA | NA | NA |
| Acoustic Pressure | 62dB (A)7m | 62dB (A)7m | 57dB (A)7m |
| Load Capacity For 40"HC(Units ) | 20 | 60 | 100 |
| Engine | Honda (Gasoline ) | YAMAHA(Gasoline) | |
| Engine Model | EC4000CX | ER2500CX | EF950 |
| Speed (Rpm) | 3000 | 3000 | 3600 |
| Prime Power ( Kw ) | 3.6 | 2.2 | 0.7 |
| Cooling System | Air -cooled | Air -cooled | Air -cooled |
| Oil Capability | 1.1L | 1.1L | 0.9L |
| Emission Level | NA | NA | NA |
| Alternator | Italy Mecc alte | Italy Mecc alte | Italy Mecc alte |
| Alternator Model | G*270H | G*160H1 | MT65 |
| Frequency ( Hz ) | 50 | 50 | 50 |
| Continued Power (Kw) | 3.6 | 2.2 | 0.7 |
| Alternator | Brushless | Brushless | Brushless |
| Excitation Mode | Capacitor exciter | Capacitor exciter | Capacitor exciter |
| Rating Voltage (V ) | 220V | 220V | |
| Alternator Insulation | H1 | H | |
| Protection Grade | Ip23 | Ip23 | |
| Mast | Manual Winch | Pneumatic Operation Mast | |
| Mast Height | 5m | 4m | 5m |
| Lighting | LAMP | LAMP | LAMP |
| Type of lights | Metal Halide Lamp | Metal Halide Lamp | Metal Halide Lamp |
| Number Power of Lights | 2*1000W | 1000W | 400W |
| Mast Lighting & Extension | Manual Operation | Pneumatic operation | Pneumatic operation |
| Luminous Efficiency | 80Lumens /Watt | 80Lumens /Watt | 80Lumens /Watt |
| Protection Glass | IP65 | IP65 | IP65 |
| Luminous Flux | 2*99000LM | 1*99000LM | 4*125LM |
| Color Temperature | 4000K | 4000K | 4000K |
| Trailer | Trailer | Trailer | Trailer |
| Manufacturer | SUOEN | SUOEN | SUOEN |
| Braking System | Foot brake | Foot brake | Foot brake |
| Tire Rim Size | Φ252mm | Φ156mm | Φ120mm |
