發電機組
1、 品牌型號：可選配
2、 額定電壓：220V
3、 額定頻率：50HZ
4、 額定功率：2.8-5.0KVA
5、 最大功率:3.2-5.5KVA
6、 使用燃料:93號汽油
7、 耗油量:1.9L/hr
8、 工作時間：13 hr
9、 油箱容量:25L
10、 凈重:68KG
燈具主體:
1、 光源功率：400W*4
2、 光通量：144000LM
3、 升降操作：電動(氣動)升降
4、 升降高度：1.6-5.8M
5、 裝箱尺寸：1200*850*900MM
6、 傾斜度：小于10度
7、 抗風力：6級
8、 總重量：198KG
| Genshent Technical Data | MO-4400 | MO-1200Q | MO-1100Q |
| 20" / 40" Loading Pcs | 20 / 40 PCS | 20 / 40 PCS | 36/ 72 PCS |
| Mast Height (Fully Extenled) | 5M | 5m | 4m |
| Weight ( Net ) | 210kg | 210kg | 98kg |
| Rated Voltage | 220V(Single Phase ) | 220V(Single Phase ) | 220V(Single Phase ) |
| Rated Power | 3.6KVA | 3.6KVA | 2.2KVA |
| Power Outlet Sockets | 2PCS*10A | 2PCS*10A | 2PCS*10A |
| Input Voltage | 220V(Single Phase ) | 220V(Single Phase) | 220V(Single Phase) |
| Fuel Tank Capacity | 25Liters | 25Liters | 15Liters |
| Fuel Tank Operating Hours | 15 hours | 15 hours | 13 hours |
| Fuel Consumption (g/kw.h) | NA | NA | NA |
| Acoustic Pressure | 62dB (A) | 62dB (A)7m | 62dB (A)7m |
| Load Capacity For 40"HC(Units ) | 20 | 20 | 60 |
| Engine | Honda (Gasoline ) | Honda (Gasoline ) | |
| Engine Model | EC4000CX | EC4000CX | ER2500CX |
| Speed (Rpm) | 3000 | 3000 | 3000 |
| Prime Power ( Kw ) | 3.6 | 3.6 | 2.2 |
| Cooling System | Air -cooled | Air -cooled | Air -cooled |
| Oil Capability | 1.1L | 1.1L | 1.1L |
| Emission Level | NA | NA | NA |
| Alternator | Italy Mecc alte | Italy Mecc alte | Italy Mecc alte |
| Alternator Model | G*270H | G*270H | G*160H1 |
| Frequency ( Hz ) | 50 | 50 | 50 |
| Continued Power (Kw) | 3.6 | 3.6 | 2.2 |
| Alternator | Brushless | Brushless | Brushless |
| Excitation Mode | Capacitor exciter | Capacitor exciter | Capacitor exciter |
| Rating Voltage (V ) | 220V | 220V | |
| Alternator Insulation | H | H1 | |
| Protection Grade | Ip23 | Ip23 | |
| Mast | Manual Winch | Manual Winch | Pneumatic Operation Mast |
| Mast Height | 5m | 5m | 4m |
| Lighting | LAMP | LAMP | LAMP |
| Type of lights | Metal Halide Lamp | Metal Halide Lamp | Metal Halide Lamp |
| Number Power of Lights | 4*400W | 2*1000W | 1000W |
| Mast Lighting & Extension | Manual Operation | Manual Operation | Pneumatic operation |
| Luminous Efficiency | 80Lumens /Watt | 80Lumens /Watt | 80Lumens /Watt |
| Protection Glass | IP65 | IP65 | IP65 |
| Luminous Flux | 4*11000LM | 2*99000LM | 1*99000LM |
| Color Temperature | 4000K | 4000K | 4000K |
| Trailer | Trailer | Trailer | Trailer |
| Manufacturer | SUOEN | SUOEN | SUOEN |
| Braking System | Foot brake | Foot brake | Foot brake |
| Tire Rim Size | Φ252mm | Φ252mm | Φ156mm |
